Technical Specifications
12 AC-225x Series Hardware Installation Manual
Dimensions
Height x Width x Depth
264 x 334 x 84.5 mm (10.4 x 13.2 x 3.4 in.)
Weight
AC-225 4.0 kg (8.7 lb)
AC-225IP 3.8 kg (8.4 lb)
AC-225U 2.7 kg (5.8 lb)
AC-225IPU 2.7 kg (5.8 lb)
Transformer (for IP models only)
AC Transformer
AC transformer 120/220 VAC/16 VAC 3A (50
VA), class 2 (not included)
PS-33 Power Supply Specifications
Input Voltage
16.5 VAC, 3 A
Backup Battery Charger Output
12 VDC, 300 mA
To access control panel – Output
Voltage 1
13.8 VDC, 1.5 A
To Relay Outputs – Output
Voltage 2
13.8 VDC, 0.9 A
PS-33 Power Supply Indication
Tamper Output (open collector)
Indicates faulty power
PS-33 Power LEDs
Power In (AC) – Green LED1
Main power
Power Out (DC) – Red LED2
Low voltage
Low Battery – Red LED3
Backup battery low voltage
For models: AC-225U and AC-225IPU
These models come without a transformer. When using a third-party
transformer, please make sure that it is rated for at least 50 W (16.5 VAC @
3A).
AC-225U and AC-225IPU have a maximum 50 W power consumption, which
means that it requires 3.0 A. This rated power is divided in the system, as
follows:
1) 300 mA for the Lead Acid Battery Charger
2) 980 mA total for four readers (when MD-D02 is used)
3) 900 mA total for the four outputs
In cases where the installation requires more power (for example high rated
magnetic locks), we recommend using an external power supply for the lock.
