Input and Output Connections
26 AC-225x Series Hardware Installation Manual
4.3 Outputs
Rosslare Security recommends the use of suppression diodes for all outputs
that activate an inductive load.
Door Lock
There are two types of door locking devices:
 Fail open (fail secure)
 Fail close (fail safe)
The following should be defined:
Single door controller:
Door 1 – OUT 1
Double door controller:
Door 1 – OUT 1
Door 2 – OUT 2
Door outputs when using MD-D02:
Double door controller:
(each door has two readers)
Door 1 – OUT 1
Door 2 – OUT 5
Four door controller:
(each door has one reader)
Door 1 – OUT 1
Door 2 – OUT 2
Door 3 – OUT 5
Door 4 – OUT 7
The output can sink current from any power supply (see Section 3.4).
For UL installations, the installer must configure the system as fail-safe to
comply with NFPA (National Fire Protection Association) regulations.
4.4 Card Readers and Keypads
Each access control panel can be connected to a maximum of two readers or 4
readers when using MD-D02. There are three available types of reader:
 Card readers
 Keypads
 Dual keypad card readers
A keypad is required for any reader mode that requires PIN code entries, such
as "Card or PIN", "PIN Only" or "Card and PIN (Secured mode)".
When connecting a reader, the following should be defined:
Single door controller:
Door 1 – Reader 1 IN/OUT
Door 1 – Reader 2 OUT/ IN
Double door controller:
Door 1 – Reader 1 IN/OUT
Door 2 – Reader 2 IN/OUT
