Introduction
8 AC-225x Series Hardware Installation Manual
1. Introduction
The AC-225 and AC-225IP family of access control panels are state-of-the-art
networked access controllers, employing the latest technology to meet the
requirements of the market.
Table 1 summarizes the family of AC-225 and AC-225IP models and their
respective descriptions.
Table 1: Description of Family of AC-225 and AC-225IP Panels
Model Name Description
AC-225-E AC-225, no onboard IP, supplied with 230 VAC
transformer
AC-225-U AC-225, no onboard IP, FCC approved and UL-294 listed,
Transformer Not Supplied
AC-225-L AC-225, no onboard IP, supplied with 110 VAC
transformer
AC-225-PCBA AC-225, no onboard IP, PCB only
AC-225IP-E AC-225IP with onboard IP, supplied with 230 VAC
transformer
AC-225IP-U AC-225IP with onboard IP, FCC approved and UL-294
listed, transformer not supplied
AC-225IP-L AC-225IP with onboard IP, supplied with 110 VAC
transformer
AC-225IP-PCBA AC-225IP with onboard IP, PCB only
• The IP models also includes onboard support for communications across a
TCP/IP network.
• The U models are for US installations, and have been approved by UL for use
as standalone units only.
When used in combination with Rosslare's AxTraxNG™ software system, the
AC-225x gives you full control over access to your premises. The system can
control both single and double door entrances and up to four doors, with MD-
D02 two Door expansion module. AC-225x supports up to 30,000 users and
uses flash memory to enable easy firmware upgrades. For more information on
the AxTraxNG system, refer to the AxTraxNG™ Software Installation and User
Manual .
The AC-225x consists of the following components:
 AC-225x controller board
 Panel enclosure
 PS-33 power supply
 Power Transformer (as described in Table 1)
 4 x 2.2 kΩ and 4 x 8.2 kΩ resistors for the supervised inputs.
