17 TECHNICAL FEATURES
Builder TEXA S.p.A.
Brand ROTARY
Model
R
3
AC50
Fluid / Group R134a / 2
Electronic refrigerant scale (Precision) ± 0.35 oz / ± 10 g
Oil quantity display resolution 0.7 oz / 20 ml
Pressure transducer Class 1.0
High Pressure (HP) gauge Ø 3.15 in / 80 mm
Low Pressure (LP) gauge Ø 3.15 in / 80 mm
Tank capacity 50 lb / 23 l
Length of service pipes 8 ft / 2,44 m
Filter assembly 1 combined filter + mechanical filter
Compressor Air-tight 0.68 cu. in / 11,1 cc
Vacuum pump
dual stage
100 l/min / 3.5 cfm
final pressure 0.44 mpsia / 0,03 mbar
Ambient temperature sensor (Resolution) 1.8 °F / 1 °C
Display TFT
SD card memory capacity 8 GB
Filter replacement (every so many)
165 lb / 75 kg
(SAE J2099)
Recovery efficiency
> 95 %
(SAE J2788)
Maximum operating pressure 350 psig / 23 bar
Operating temperature 50 ÷ 122 °F / 10 ÷ 50 °C
Storing temperature - 13 ÷ 140 °F / - 25 ÷ 60 °C
Sizes
H: 442.44 in / 1078 mm
L: 24.8 in / 630 mm
P: 27.8 in / 706 mm
Weight 212 lb / 96 kg
Supply voltage 115 Vac
Frequency 60 Hz
Power 1200 W
Conformity
Conforms to UL Std. 1963
Cert. to CSA Std. C22.2 No.120
Certified by Intertek to meet SAE J2788
50
