rotork IQT Series User Manual

Oil
The IQT range are factory filled with
80% Texaco Texamatic 9330 automatic
transmission fluid (ATF) and 20%
Kerosene. Equivalent ATF lubricants
meeting the Dexron® 2 or Mercon®
specification may be used. For
operating ambient temperatures below
-20ºC / -4ºF, 20% kerosene by volume
should be added.
NOTE: Excludes second stage gearbox
if fitted.
Food grade lubricating oil is available
as an alternative: contact Rotork.
71
Weights and Measures
11
Actuator Size Nett Weight Oil Capacity
kg/lbs litres/pt.-US
IQT 125 23/51 0.5/1.1
IQT 250 23/51 0.5/1.1
IQT 500 23/51 0.5/1.1
IQT 1000 37/82 0.75/1.6
IQT 2000 37/82 0.75/1.6

rotork IQT Series Specifications

General

Data Logging	Yes
Housing Material	Aluminum alloy
Type	Electric
Ingress Protection	IP68
Communication Protocols	Foundation Fieldbus, Profibus, Modbus
Control Signal	4-20mA
Ambient Temperature Range	+70°C
Communication	Foundation Fieldbus
Mounting	quarter-turn, linear
Torque Range	10 Nm to 3000 Nm
