rotork IQT Series User Manual

Refer to actuator nameplate for unit specific approval details
Eur
opean – Hazardous area
EExd IIB T4. ATEX (94/9/EC) II 2GD
CENELEC Norm EN50014 and EN50018
Temperature -20°C to +70°C (-4°F to +158°F).
*Option -30°C to +70°C (-22°F to +158°F).
*Option -40°C to +70°C (-40°F to +158°F).
*Option -50°C to +40°C (- 58°F to +104°F).
EExd IIC T4. ATEX (94/9/EC) II 2GD
CENELEC Norm EN50014 and EN50018.
Temperature -20°C to +70°C (-4°F to +158°F).
EExde IIB T4. ATEX (94/9/EC) II 2GD
CENELEC Norm EN50014, EN50018 and EN50019.
Temperature -20°C to 70°C (-4°F to +158°F).
*Option -30°C to +70°C (-22°F to +158°F).
*Option -40°C to +70°C (-40°F to +158°F).
*Option -50°C to +40°C (-58°F to +104°F).
EExde IIC T4. ATEX (94/9/EC) II 2GD
CENELEC Norm EN50014, EN50018 and EN50019.
Temperature -20°C to +70°C (-4°F to +158°F).
International – Hazardous area
IEC. Exd IIB T4
IEC60079-0 and IEC60079-1 for Exd IIB T4
Temperature -20°C to +60°C (-4°F to +140°F)
IEC. Exd IIC T4
IEC60079-0 and IEC60079-1 for Exd IIC T4
Temperature -20°C to +60°C (-4°F to +140°F)
USA – hazardous Area
FM. Class 1, Division 1, Groups C, D, E, F, G hazardous areas.
Factory Mutual - Explosionproof to NEC Article 500.
Temperature -30°C to +60°C (-22°F to +140°F).
*Option -40°C to +60°C (-40°F to +40°F).
*Alternative for Group B hazardous area. Temperatures as for Groups C and D.
Canada – hazardous Area
CSA EP. Class 1, Division 1, Groups C and D hazardous areas.
Canadian Standard Association - Explosionproof
Temperature -30°C to +70°C -22°F to +158°F).
*Option -50°C to +40°C (-58°F to +104°F).
*Alternative for Group B hazardous area. Temperatures as for Groups C and D.
International Non hazardous
WT: Standard watertight, BS EN 60529 :1992, IP68, 7 metres/72 hours.
Temperature -30°C to +70°C (-22°F to +158°F).
*Option -40°C to +70°C (-40°F to +158°F).
*Option -50°C to +40°C (-58°F to +104°F).
US – Non hazardous
NEMA 4, 4X and 6.
Temperature -30°C to +70°C (-22°F to +158°F).
*Option -40°C to +70°C (-40°F to +158°F).
*Option -50°C to +40°C (-58°F to +104°F).
Canada – Non hazardous
CSA WT: Canadian Standard Association –Watertight.
Wiring and components complying with CSA Enclosure 4 and 4X.
Temperature -30°C to +70°C (-22°F to +158°F).
*Option -40°C to +70°C (-40°F to +158°F).
*Option -50°C to +40°C (-58°F to +104°F).
Rotork can supply actuators to national standards not listed above.
For details please contact Rotork.
73
IQ Approvals
12

rotork IQT Series Specifications

General

Data Logging	Yes
Housing Material	Aluminum alloy
Type	Electric
Ingress Protection	IP68
Communication Protocols	Foundation Fieldbus, Profibus, Modbus
Control Signal	4-20mA
Ambient Temperature Range	+70°C
Communication	Foundation Fieldbus
Mounting	quarter-turn, linear
Torque Range	10 Nm to 3000 Nm
