Roxell FLEX-AUGER FA 90 - Installing the Tubes

ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-53
FA 75 & FA90
FA 125
FA90: Ø60 - L=3000 - 03700861 Ø65 x 2 x 80 - 13701644 Ø65 x 2 x 80 - 13701263
FA90: Ø44.5 - L=3000 - 00102269
FA75: Ø32 - L=3000 - 03103066
FA90: Ø41.5x80 - 13204116
FA75: Ø28.7x80 - 13109812
FA90:
FA75: 13109160
25 ø
6.5 (2x)
25
ø
6.5
10
20mm
Mount the tube
in the intake boot
Connect t he tubes if
length is more than 3m.
Tube end 20mm
past the second intake boot
Tube Connection piece
Tube end :
Bolt M6
Guide piece
Bolt M6
Bolt M6
No extra's
Tube Connection piece
Tube end :
Drill holes Drill holes
Tube end :
TO INSTALL THE TUBE
