RSP STC20 - Cleaning and Lubrication of Swivel Tool Changer

18 M0412-1 ver 3.0
3.4.3 Cleaning and lubrication of swivel tool changer
The following maintenance activities should be carried out on the STC every 6
th
month or
after 250,000 tool changes, whichever comes first.
Action
Note
Clean locking balls
Check the looking balls
and wipe them clean with
a lint free cloth.
WARNING! Risk of getting
squeezed between piston
and ball holder when the
piston is taking closed
position
Lubricate looking balls
Apply a small amount of
grease (Molykote
BR2Plus) on the locking
balls.
NOTE! It is important that
this is done or else there is
a risk that the tool
attachment jams.
Clean air sealings
Wipe air sealings clean
with a lint free cloth.
