RSP STC20 - Tightening Torques; Recommended Equipment; Required Products

M0412-1 ver 3.0 7
1.3 Tightening torques
Tightening torques for mounting (screw class 8.8)
Dimension
Torque
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
24 Nm
M10
47 Nm
M12
82 Nm
M16
200 Nm
1.4 Recommended equipment
Equipment recommended for installation and maintenance work
Tools
Applications
Complete set of Allen keys
For dismounting and mounting
Torx key
For all socket head cap screws
Plastic mallet
For mounting of air sealings
Pair of pliers
For dismounting the signal pins
Screw driver
For removing the air sealings
Torque wrench
For dismounting and mounting
1.5 Required products
Product
Specification
Note
Grease, 3HXG1000-413
Magnalube-G, Teflon grease
Air sealings and O-rings.
Grease I0876
Molykote BR2Plus
For locking balls.
Cleaning agent
Industrial alcohol or similar
For cleaning of tool changer and tool
attachment.
Cloth
Lint free cloth
For cleaning.
NOTE! Chemical resistance protective gloves are recommended when using grease
or cleaning agents such as industrial alcohol. Safety goggles are recommended
when working with cleaning agents such as industrial alcohol. Adequate ventilation
should be provided when chemical substances are used.
