Version 1.4 Page | 12
“Message” icon is displayed in the status bar when there are messages on the handset that have
not been read.
“Alarm” icon is displayed in the status bar and indicates that an alarm has been set on the handset.
“Silent Alarm” icon is displayed in the status bar when the handset is in silent mode, or if the
volume is set to the mute and an alarm is enabled.
“Sound off”/”Silent” icon is displayed in the status bar when silent mode is enabled on the
handset.
“Keylock” icon indicates when the keypad is locked, and the user needs to long press the *-key to
be able to use the handset again.
“Do not disturb” icon is displayed in the status bar when this feature is enabled; in this case the
handset does not react on any incoming calls.
“HD” icon is displayed during a call if the quality of the call is “High Definition” and hereby using
the 722 codec (also called a wideband call).
4.2 Menu icons
All the menus available on the handset are displayed when the menu key is pressed from idle. The
available menus are seen in the screen below.
The status bar at the top of the display is always displayed independent of which menu is selected, and
the softkey bar gives the possible options to select in every menu. In the active area of the screen the
name of the menu selected is displayed at top, and all the available menus to select are displayed.
During navigation across the different menus the highlighted icon is moving to indicate where the
navigation key is. The menu icons are showed and shortly explained in the following:
The “Contacts” menu contains all names/numbers in the local phonebook.
The “Central directory” menu contains all names/numbers in the central directory of the
system. This is set up in the web interface of the base system (see the additional base station manual
document for further information on this via [2])
