Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7761-CM Cable Modem Access Point
Figure 13 and Figure 14 identify the 7761-CM Cable Modem AP (CMAP) external
features.
Figure 13. CMAP parts and connectors (Connector side)
Antenna
Connector
DC Connector
Coaxial Cable
Connector B
Coaxial Cable
Connector A
Ethernet
Port
Vertically-polarized antennas
Horizontally-polarized antenna
