25
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Connectors
The CMAP provides the following connectors:
■ PoE-Out connector: RJ-45 port that can supply power to devices that support PoE.
■ Three N-type antenna connectors: Connects to the three 5GHz antennas (not
supplied, with the CMAP).
■ DC power supply (Ruckus Wireless part number 705-60244-002): Connected
through a 4-pin connector, which is normally unused. It may be used to supply DC
power to the unit for testing or configuration purposes. The supply has a reset
switch that may be used to reset the unit.
■ Coaxial cable connectors (see Figure 13): Connector A may be connected to a
spectrum analyzer or signal analyzer to allow monitoring of the downstream signal.
Connector B must be connected to the CMTS backbone and AC power when
deployed in the field.
Ethernet/PoE-Out Port
The CMAP provides one 10/100Mbps RJ45 Ethernet port, which also functions as a
PoE-Out port. The PoE-Out port, which can supply up to 15.4 watts (compliant with
802.3af), can be used to power PoE-capable devices (for example, an IP-based
surveillance camera).
NOTE: The PoE-Out function is non-operational when the unit is powered via the 12
VDC connector.
NOTE: By default, both Ethernet data and PoE-Out are enabled. If necessary, you
can disable PoE-Out from the Web interface.
