RuggedCom RUGGEDBACKBONE RX5000 Hardware Installation Guide

3. Installation
RuggedCom® RuggedBackbone™ 23 RX5000 Installation Guide Rev 107
3.2.2. AC Power Supply Wiring
Figure 3.14. AC Power Schematic – Integrated Earth Connection
If the ground terminal on the Figure 3.12, “RX5000 Power Connector” is not connected to
safety earth, a connection must be provided from the chassis ground terminal, as shown
in Figure 3.15, “AC Power Schematic – Separate Earth Connection”.
Figure 3.15. AC Power Schematic – Separate Earth Connection
