4. Technical Specifications
RuggedCom® RuggedBackbone™ 27 RX5000 Installation Guide Rev 107
4. Technical Specifications
4.1. Power Supply Specifications
Input Range
Power Supply Type
Min Max
Internal Fuse Rating
Max. Power
Consumption
a
HI (125/250 VDC)
b
88 VDC 300 VDC 6.3A, 250V(T)
c
84 W
d
HI (110/230 VAC)
b
85 VAC 264 VAC 6.3A, 250V(T)
c
84 W
d
a
Power consumption varies based on configuration, i.e. the number and type of ports. Each 10/100Base-TX port consumes
roughly 1W less than a fiber optic port.
b
The “HI” power supply is the same power supply for both AC and DC.
c
(T) denotes time-delay fuse. Internal fuse is not user-replaceable.
d
Rating at 85°C ambient temperature at worst-case load.
Table 4.1. Power Supply Specifications
4.2. Critical Alarm Relay Specifications
Parameter Value (Resistive Load)
Max Switching Voltage 250 VAC, 125 VDC
Rated Switching Current 2A@250VAC, 2A@30VDC
Table 4.2. Critical Alarm Relay Specifications
4.3. Copper Ethernet Port Specifications
The RX5000 can be ordered with several different modules which contain 10/100Tx or 10/100/1000Tx
Ethernet ports. All copper Ethernet ports have the following specifications:
Parameter Specification Notes
Speed 10/100 or 10/100/1000 Mbps Auto-negotiating
Duplex FDX / HDX Auto-negotiating
Cable-Type > Category 5 Shielded/Unshielded
Wiring Standard TIA/EIA T568A/B Auto-Crossover, Auto-Polarity
Max Distance 100 m
Connector RJ45
Isolation 1.5kV RMS 1-minute
Table 4.3. Copper Ethernet Port Specifications
