43
COMPILER TECO/ATI ENDORSEDDATE
01.08.2003
REG. CODE
1-5302-620
MODEL N°
50902
DATE OF ISSUE
08-03
REVISION 00
XIV
94
93
92
5
15
30
30
30
5
0
0
30%
50%
70%
100%
2000
3000/3600
3000/3600
3000/3600
3000/3600
3000/3600
ENGINE TESTING
Running-in table
LoadTime (min) RPM
In order to check that the setting is correct, without tools,
accelerate the engine a few times with no load and check
the exhaust fumes.
Delivery of diesel fuel is correctly calibrated when the
exhaust gas is slightly coloured by smoke; change the
adjustment if necessary by turning the adjustment screw
(fig. 94).
Engine power curves are reported at page 12.
Testing engine on brake
After having placed the engine on the brake (fig. 92), proceed with
the following operations:
1.Check oil level (fig. 93).
2.Start engine and run at minimum speed.
3.Check oil pressure on pressure gauge (fig. 90).
4.Run engine in before testing it at full power.
