Ruijie Reyee RAP6260-D User Manual

Hardware Installation and Reference Guide Product Overview
8
Table 1-5 Power Supply Mode
Power Input
Standard PoE: IEEE 802.3bt standard, backward compatible with the IEEE 802.3at
standard
Local power supply: 48 V DC/1 A
Power Supply Mode
2.4 GHz
5 GHz
Data Rate
Max. Power
Consumption
IEEE 802.3bt
Standard
(Recommended)
4 x 4
4 x 4
5952 Mbps
40 W
60 W Passive PoE
Adapter
(Recommended)
4 x 4
4 x 4
5952 Mbps
40 W
Local Power Supply
(48 V DC /1 A)
4 x 4
4 x 4
5952 Mbps
40 W
IEEE 802.3at
Standard
2 x 2
2 x 2
2976 Mbps
25 W
Note: The 60 W passive PoE adapter is an optional accessory. The access point is not 802.3af-compliant.
1.6 Heat Dissipation
Maintain a sufficient clearance around the access point for proper ventilation.

Ruijie Reyee RAP6260-D Specifications

General

Brand	Ruijie
Model	Reyee RAP6260-D
Category	Wireless Access Point
Language	English
