13
Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233
800.764.1028 sales@rearviewsafety.com
www.rearviewsafety.com
UP:
Switch the channel without auto scan and trigger function turned on;
Move the red box in the magnified mode;
Move the displayed place of the magnified image.
DOWN:
Switch the channel without special mode such as auto scan and trigger function turned on;
Move the red box in the magnified mode;
Move the displayed place of the magnified image.
P/N:
Shrink the red box if the red box is shown in the magnified mode.
LANG:
Switch to dierent languages on some menus.
REST:
Reset the system.
AV:
Magnify the red box if the red box is shown in the magnified mode.
SEL:
Enter the menu which the cursor selects;
Show/hide a red box to magnify the displayed area when in single view display mode and without
special mode such as auto scan or trigger function turned on;
Magnify the image to full screen when the red box is shown in the magnified mode.
MENU:
Exit to the main menu or return to the previous menu;
Return the magnified image to normal size when the green box is shown in the magnified mode.
