32
Rear View Safety, 1797 Atlantic Ave., Brooklyn NY 11233
800.764.1028 sales@rearviewsafety.com
www.rearviewsafety.com
7.1 WIRELESS CHANNEL CONNECTION
Red wire to positive power supply
of DC/10~32V.
Black wire to Ground.
Connect the camera and display
to the same DC power supply to
achieve pairing.
Connect Camera
7.WIRELESS CHANNEL CONNECTION AND DISPLAY
DC/12V
