LRF 3013 Integrator Manual
Document number: TML 913655 ver A
Confidential & Proprietary Safran Vectronix AG – All rights reserved
- Time between power on and first laser pulse is ca 150 ms
- Time between power on and the availability of the range result on the UART interface
is below 500 ms
- The average current consumption during lasing is 250 mA
- 130 mA current consumption when LRF Module is powered on, but inactive
- Ca 15 µA current consumption when the LRF Module is power off
Figure 15: Start-up behaviour with 5 V power supply
Figure 15 shows the current consumption behavior of LRF 3013 during start-up. The diagram shows a
few current peaks of about 0.9 A and the maximum current peak of ca. 1.3 A. (Keep in mind that current
peaks depend on the internal resistance of the power supply)
