FP5/GP5User’s Manual 47
n078Over/Undertorque
detection level OL3
(Torq Det Level)
Unit: 1%
Setting range: 30~200%
100% = inverter rated current
160% 74
n079
Over/Undertorque detec-
tion delay time OL3
(Torq Det Time)
Unit: 0.1s
Setting range: 0.1~10.0s
0.1s 74
n080
On-delay timer
(On-Delay Timer)
Unit: 0.1s
Setting range: 0.0~25.5s
0.0s 80
n081Off-delay timer
(Off-Delay Timer)
Unit: 0.1s
Setting range: 0.0~25.5s
0.0s 80
n082DB resistor overheat
function rH
(DB Resistor Prot)
LED
Setting LCD Setting Description
0 Disabled No DB protection calculated or provided
1 Enabled Protection provided for Yaskawa 3% ED resistor
Disabled
-
n083
Input phase loss
detection level SPI
(In Ph Loss Lvl)
Unit: 1%
Setting range: 1~100%
When setting is 100%, this function is disabled.
7% 65
n084
PID selection
(PID Mode)
LED
Setting LCD Setting Description
0 Disabled PID disabled
1 Enabled D=Fdbk PID enabled
2 Enabled D=Fdfwd PID w / Feed forward
3 Enabled RevFdbk PID w / Inverted feedback
Disabled
66,96
n085
Feedback calibration gain
PID
(PID Fdbk Gain)
Unit: 0.01
Setting range: 0.00~10.00
1.00 66
n086
Proportional gain PID
(PID P Gain)
Unit: 0.01
Setting range: 0.0~10.0
1.0 66
n087
Integral time PID
(PID I Time)
Unit: 0.1s
Setting range: 0.0~100.0s
10.0s 66
n088Derivative time PID
(PID D Time)
Unit: 0.01s
Setting range: 0.00~1.00s
0.00s 66
n089
Limit of integral value PID
(PID I Limit)
Unit: 1%
Setting range: 0~109%
100% 67
n090
Feedback loss detection
PID
(PID FdbkLoss Sel)
LED
Setting LCD Setting Description
0 Disabled Detection is disabled.
1 Multi-function Output Only Detection is enabled.
Disabled
-
n091
Feedback loss detection
level PID
(PID FdbkLoss Lvl)
Unit: 1%
Setting range: 0~100%
0% -
n092
Feedback loss detection
delay time PID
(PID FdbkLoss Tim)
Unit: 0.1s
Setting range: 0.0~25.5s
1.0s 66
n093PID output selection
(PID Output Sel)
LED
Setting LCD Setting
0 Not Inverted
1 Inverted
Not
Inverted
67
n094
Sleep function start level
PID
(Sleep Start Lvl)
Unit: 0.1Hz
Setting range: 0.0~400.0Hz
0.0Hz 67
n095Sleep function delay time
PID
(Sleep Delay Time)
Unit: 0.1s
Setting range: 0.0~25.5s
0.0s 67
No. Function Name
(LCD Operator Display)
Description Factory
Default
User
Setting
Ref.
Page
Chapter 3 - Programming Features
FP5/GP5 Parameters
