48 FP5/GP5 User’s Manual
n096
Energy saving selection
(Energy Save Sel)
LED
Setting LCD Setting Description
0 Disabled Energy saving is disabled.
1 Enabled Energy saving is enabled.
Disabled
55,96
n097Energy saving gain K2
(Energy Save Gain)
Unit: 0.01
Setting range: 0.00~655.0 (0=No energy saving)
kVA
dependent
55
n098Energy saving voltage
lower limit at 60Hz
(EngSavVLLmt@60Hz)
Unit: 1%
Setting range: 0~120%
75% 55
n099Energy saving voltage
lower limit at 6Hz
(EngSavVLLmt@6Hz)
Unit: 1%
Setting range: 0~25%
12% 55
n100Time of average kW -
Energy saving
(EngSavTime/AvgkW)
Unit: 1 = 25ms
Setting range: 0~200
1 -
n101
Modbus time over
detection
(MODBUS Timeout)
LED
Setting LCD Setting Description
0 Disabled Time Over Detection is disabled.
1 Enabled Time Over Detection is enabled.
Enabled
-
n102MODBUS stop method at
communication error CE
(MODBUS Fault Stop)
LED
Setting LCD Setting Stop method
0 Ramp STOP/Decel 1 Ramp to stop - Decel 1 (fault)
1 Coast to STOP Coast to stop (fault)
2 Ramp STOP/Decel 1 Ramp to stop - Decel 2 (fault)
3 Continue Oper Continue operation (alarm)
Coast to
STOP
-
n103MODBUS frequency ref-
erence unit
(MODBUS Fref Unit)
LED
Setting LCD Setting Stop method
0 1=0.1Hz 0.1Hz / 1
1 2=0.01Hz 0.01Hz / 1
2 3000=100% 100% / 30000
3 1=0.1% 0.1% / 1
1=0.1Hz
62
n104
MODBUS slave address
(MODBUS Address)
Unit: 1
Setting range: 0~31
1 62
n105MODBUS BPS selection
(MODBUS Baud Rate)
LED
Setting LCD Setting
0 2400 Baud
1 4800 Baud
2 9600 Baud
9600 Baud
61
n106
MODBUS parity selection
(MODBUS Parity)
LED
Setting LCD Setting
0 No parity
1 Even parity
2 Odd parity
No
parity
61
n107Slip compensation gain
(Slip Comp Gain)
Unit: 0.1% [of Base Frequency (n013)]
Setting range: 0.0 ~ 9.9%
0.0% 77
n108Motor no-load current
(Mtr No-Load Amp)
Unit: 1% [of Motor Rated Current (n033)]
Setting range: 0 ~ 99%
30% -
n109Slip compensation pri-
mary delay time constant
(Slip Comp Delay)
Unit: 0.1s
Setting range: 0.0 ~ 25.5s
2.0s 77
n110Operator connection fault
detection selection
(Oper Detect Flt)
LED
Setting LCD Setting
0: Disabled
1: Enabled
Disabled
-
n111Local / Remote
changeover function
selection
(LOC/REM Change)
LED
Setting LCD Setting
0 Cycle Extern RUN command
1 Acept Extern RUN command
Cycle
Extern
RUN
37
No. Function Name
(LCD Operator Display)
Description Factory
Default
User
Setting
Ref.
Page
Chapter 3 - Programming Features
Parameter Set-up & Initialization
