Advanced Program Group (continued)
61
A453 [Boost Select] Related Parameter(s): d004, P101, P102
Sets the boost voltage (% of P101 [Motor NP Volts]) and redefines the Volts per Hz curve. (1)
(1) Drive may add additional voltage unless option 5 is selected.
Options 1 “30.0, VT”
2 “35.0, VT”
Variable Torque
3 “40.0, VT”
4 “45.0, VT”
5 “0.0 no IR”
6 “0.0”
Constant Torque
7 “2.5, CT”
[Default for
3.7, 5.5, 7.5 & 11.0 kW
(5.0, 7.5, 10.0 & 15.0 HP) Drives]
8 “5.0, CT” (Default)
9 “7.5, CT”
10 “10.0, CT”
11 “12.5, CT”
12 “15.0, CT”
13 “17.5, CT”
14 “20.0, CT”
