Saftronics HPVFE User Manual

77
Table B.C Dynamic Brake Modules
Minimum
ResistanceΩ
Input Voltage
KW
HP
240V 50/60 Hz
3-Phase
5.5
7.5
18
7.5
10.0
12
480V 50/60 Hz
3-Phase
5.5
7.5
60
7.5
10.0
39
11.0
15.0
36
NOTE ：
(1) The resistors listed in this table are rated for 5% duty cycle.
(2) Use of Solcom&Hapn resistors is always recommended. The resistors listed have been carefully
selected for optimizing performance in a varity of applications. Alternative resistors may be used,
however care must be taken when making a selection.
(3) 11kW Requires two resistors wired in parallel.
Table B.D EMC Line Filters
Drive Ratings
Build-in Filter
240V 50/60 Hz
3- Phase
0.2
0.25
0.4
0.5
0.75
1
1.5
2
2.2
3
480V 50/60 Hz
3- Phase
0.4
0.5
0.75
1
1.5
2
2.2
3
3.7
5
5.5
7.5
7.5
10
11
15
