VM1000B
- 25 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
1：The asynchronous machine static tuning.
2：The asynchronous machine is fully tuned
F2.12
G/P type selection
1：General model (G) (constant torque
load model)
2：Pump model (P) (draught fan, water
pump type load model)
Model
dependent
●
020C
F3 Group: vector parameters
F3.00
Speed loop proportional
gain 1
1 ～ 100
30
○
0300
F3.01
Speed loop integral time 1
0.01s ～ 10.00s
0.50s
○
0301
F3.02
Switchover frequency 1
0.00 ～ F3.05
5.00Hz
○
0302
F3.03
Speed loop proportional
gain 2
1 ～ 100
20
○
0303
F3.04
Speed loop integral time 2
0.01s ～ 10.00s
1.00s
○
0304
F3.05
Switchover frequency 2
F3.02 ～ F0.10
10.00Hz
○
0305
F3.06
Slip compensation
coefficient of vector
control
50% ～ 200%
100%
○
0306
F3.07
Speed loop filter time
constant.
0.000s ～ 0.100s
0.000s
○
0307
F3.08
Speed control torque
upper limit
0.0% ～ 200.0%
150.00%
○
0308
F3.09
Speed/torque control
0: Speed control
1. Torque control
0
●
0309
F3.10
Torque upper limit source
in torque control
0: Digital setting
1: AI1
2: AI2
3: Reserved
4: Reserved
5: Communication setting
6: MIN(AI1,AI2)
7: MAX(AI1,AI2)
0
●
030A
F3.11
Digital setting of torque
upper limit in torque
control
-200.0% ～ 200.0%
150.00%
○
030B
F3.12
Forward maximum
frequency of torque
control
0.00Hz ～F0.10
50.00Hz
○
030C
F3.13
Reverse maximum
frequency of torque
0.00Hz ～F0.10
50.00Hz
○
030D
