SAJ VM1000B

VM1000B
- 26 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
control
F3.14
Acceleration time of
torque control
0.00s ～ 650.00s
0.00s
○
030E
F3.15
Deceleration time of
torque control
0.00s ～ 650.00s
0.00s
○
030F
F3.16
Torque stiffness
coefficient
10.0%~120.0%
100.00%
●
0310
F3.17
M axis current loop
proportional gain
0 ～ 60000
2000
○
0311
F3.18
M axis current loop
integral gain.
0 ～ 60000
1300
○
0312
F3.19
T axis current
proportional gain
0 ～ 60000
2000
○
0313
F3.20
T axis current integral
gain
0 ～ 60000
1300
○
0314
F3.21
The speed loop integral
separation
0: Invalid
1: Valid
0
○
0315
F4 Group: control parameters
F4.00
V/F curve setting
0: Linear V/F
1: Multi-point V/F
2: Square V/F
3~9: Reserved
10: V/F complete separation
11: V/F half separation
0
●
0400
F4.01
Torque boost
0.0%（fixed torque boost）
0.1% ～ 30.0%
Model
dependent
○
0401
F4.02
Cut-off frequency of
torque boost
0.00Hz ～F0.10
50.00Hz
●
0402
F4.03
Multipoint V/F frequency
1
0.00Hz ～ F4.05
0.00Hz
●
0403
F4.04
Multipoint V/F voltage 1
0.0% ～ 100.0%
0.00%
●
0404
F4.05
Multipoint V/F frequency
2
F4.03 ～ F4.07
0.00Hz
●
0405
F4.06
Multipoint V/F voltage 2
0.0% ～ 100.0%
0.00%
●
0406
F4.07
Multipoint V/F frequency
3
F4.05 ～ F2.04
0.00Hz
●
0407
F4.08
Multipoint V/F voltage 3
0.0% ～ 100.0%
0.00%
●
0408
F4.09
V/F slip compensation
0.0% ～ 200.0%
0.00%
○
0409
F4.10
V/F over-excitation gain
0 ～ 200
0
○
040A
