VM1000B
- 27 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
F4.11
V/F oscillation
suppression gain
0 ～ 100
Model
dependent
○
040B
F4.12
Voltage source for V/F
separation
0: Digital（F4.13）
1: AI1
2: AI2
3: Reserved
4: Reserved
5: Multi-speed instructions
6: Simple PLC
7: PID
8: Communication setting (100% corresponds to
the rated motor voltage)
0
○
040C
F4.13
Voltage digital setting
for V/F separation
0V ～F2.02
0V
○
040D
F4.14
Voltage rise time of
separation
0.0s ～ 1000.0s
(It indicates the time for the voltage rising from
0 to rated motor voltage.)
0.0s
○
040E
F4.15
Reserved
-
-
-
040F
F4.16
Auto voltage regulation
(AVR)
0：Disable
1：Enable
1
●
0410
F5 Group: input terminal
F5.00
DI1 terminal function
selection
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: Three-wire operation control
4: Forward point movement (FJOG)
5: Reverse point movement (RJOG)
6: Terminal UP
7: Terminal DOWN
8: Free stopping
9: Reset
10: Run pause
11: External faults often open input
12: Multi-speed instruction terminal 1
13: Multi-speed instruction terminal 2
14: Multi-speed instruction terminal 3
15: Multi-speed instruction terminal 4
16: Terminal 1 for acceleration/deceleration time
selection
17: Terminal 2 for acceleration/deceleration time
selection
18: Frequency source switchover（terminal and
keypad）
19: UP/DOWN setting clear
20: Command source switchover terminal 1
21: Acceleration/deceleration prohibited
22: PID pause
1
●
0500
F5.01
DI2 terminal function
selection
4
●
0501
F5.02
DI3 terminal function
selection
9
●
0502
F5.03
DI4 terminal function
selection
12
●
0503
F5.04
DI5 terminal function
selection
13
●
0504
F5.05
DI6 terminal function
selection
0
●
0505
F5.06 –
F5.09
Reserved
-
-
-
F5.10
VDI terminal function
selection
0
●
050A
F5.11~
F5.14
Reserved
-
-
-
