SAJ VM1000B

VM1000B
- 37 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
F8.38
Any current reaching 1
0.0% ～ 300.0%(motor rated current)
100.00%
○
0826
F8.39
Any current reaching 1
amplitude
0.0% ～ 300.0%(motor rated current)
0.00%
○
0827
F8.40
Any current reaching 2
0.0% ～ 300.0%(motor rated current)
100.00%
○
0828
F8.41
Any current reaching
2amplitude
0.0% ～ 300.0%(motor rated current)
0.00%
○
0829
F8.42
Timing function
0: Disabled
1: Enabled
0
●
082A
F8.43
Timing duration source
0: F8.44
1: AI1
2: AI2
3: Reserved
0
●
082B
F8.44
Timing duration
0.0Min ～ 6500.0Min
0.0Min
●
082C
F8.45
AI1 input voltage lower
limit
0.00V ～ F8.46
3.10V
○
082D
F8.46
AI1 input voltage upper
limit
F8.45 ～ 10.00V
6.80V
○
082E
F8.47
IGBT temperature
threshold
0℃～ 100℃
75℃
○
082F
F8.48
Fast current limiting
Single-digit:
0: Disabled
1: Enabled
Ten’s digit:
0: Disable Err40 Display
1: Enabled Err40 Display
11
○
0830
F8.49
Random carrier mode
0: Closed
1: Random carrier mode 1
2: Random carrier mode 2
3: Random carrier mode 3
4: Random carrier mode 4
5: Random carrier mode 5
6～10: Reserved
0
○
0831
F9 Group: process control PID function
F9.00
PID setting source
0: F9.01
1: AI1
2: AI2
3: Reserved
4: Reserved
5: Communication setting
6: Multi-speed instructions
0
○
0900
F9.01
PID digital setting
0.0% ～ 100.0%
50.0%
○
0901
F9.02
PID feedback source
0: AI1
0
○
0902
