SAJ VM1000B

VM1000B
- 39 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
F9.23
Two output deviation
reverse maximum
0.00% ～ 100.00%
1.00%
○
0917
F9.24
PID integral property
Single-digit: Integration separation
0: Disabled
1: Enabled
Ten’s digit: Output to limit value
0: Continue the integral
1: Stop the integral
0
○
0918
F9.25
Detection value of PID
feedback loss
0.0%: No judging feedback loss
0.1% ～ 100.0％
0.0%
○
0919
F9.26
Detection time of PID
feedback loss
0.0s ～ 20.0s
0.0s
○
091A
F9.27
PID operation at stop
0: No PID operation at stop
1: PID operation at stop
0
○
091B
F9.28
PID function selection
0: Normal PID
1: Sleep PID
0
○
091C
F9.29
PID sleep threshold
0.0% ～ 100.0%
60.0%
○
091D
F9.30
PID sleep delay
0.0 ～ 3600.0s
3.0s
○
091E
F9.31
ID wake-up threshold
0.0% ～ 100.0%
20.0%
○
091F
F9.32
PID wake-up time delay
0.0 ～ 3600.0s
3.0s
○
0920
F9.33
PID Minimum output
0: F0.14
1: 0 Hz
0
●
0921
FA Group: fault and protection
FA.00
Motor overload protection
selection
0: Disabled
1: Enabled
1
○
0A00
FA.01
Motor overload protection
gain
0.20 ～ 10.00
1
○
0A01
FA.02
Motor overload warning
coefficient
50% ～ 100%
80%
○
0A02
FA.03
Overvoltage stall gain
0 ～ 100
10
○
0A03
FA.04
Overvoltage stall
protective voltage
120% ～ 150%
130%
○
0A04
FA.05
Overcurrent stall gain
0 ～ 100
Model
dependent
○
0A05
FA.06
Overvoltage stall
protective current
100% ～ 200%
150%
○
0A06
FA.07
Short-circuit to ground
upon power-on
0: Disabled
1: Enabled
1
○
0A07
FA.08
Fault auto reset times
0 ～ 5
0
○
0A08
