101
F6.24
Corresponding physical quantity of
AO1 output lower limit
-200.0% ～ 200.0% 0.0%
F6.25
AO1 output lower limit
0.00 ～ 10.00V 0.00
F6.26
Corresponding physical quantity of
AO1 output upper limit
-200.0% ～ 200.0% 100.0%
F6.27
AO1 output upper limit
0.00 ～ 10.00V 10.00
F6.28
Corresponding physical quantity of
AO2 output lower limit
-200.0% ～ 200.0% 0.0%
F6.29
AO2 output lower limit
0.00 ～ 10.00V 0.00
F6.30
Corresponding physical quantity of
AO2 output upper limit
-200.0% ～ 200.0% 100.0%
F6.31
AO2 output upper limit
0.00 ～ 10.00V 10.00
F6.32
Corresponding physical quantity of
DO output lower limit
-200.0% ～ 200.0% 0.0%
F6.33
DO output lower limit
0.00 ～ 50.00KHz 0.00
F6.34
Corresponding physical quantity of
DO output upper limit
-200.0% ～ 200.0% 100.0%
F6.35
DO output upper limit
0.00 ～ 50.00KHz 50.00
4.2 Detailed Function Description
F6.36
AI multipoint curve selection
0000 ～ 0011 0000
the unit of LED: AI1 multipoint curve
selection
0: forbidden
1: e󽗈ective
the tens of LED: AI2 multipoint
curveselection
0: forbidden
1: e󽗈ective
the hundreds of LED: anolog input
signal selection
0: AI1 and AI2 input signal 0 ～ 10V
1: AI1 input signal 4 ～ 20mA, AI2
input signal 0 ～ 10V
2: AI2 input signal 4 ～ 20mA, AI1
input signal 0 ～ 10V
3: AI1 and AI2 input signal 4 ～ 20mA
the thousands of LED: reserved
F6.37
AI1 curve min input
0.00 ～【F6.39】 0.00
F6.38
AI1 curve min input corresponding
setting
-200.0% ～ 200.0%
Note: range associated
with F6.00
0.0%
F6.39
AI1 curve in󽗊exion point 1 input
【F6.37】～【F6.41】 3.00
F6.40
AI1 curve in󽗊exion point 1 input
corresponding setting
-200.0% ～ 200.0%
Note: range associated
with F6.00
30.0%
F6.41
AI1 curve in󽗊exion point 2 input
【F6.39】～【F6.43】 6.00
