Sako SKI600 - Page 109

103
4.2 Detailed Function Description
0: control terminal idle
1: forward running (FWD)
Short-circuit terminal with COM, VFD runs
forward. Valid only when F0.06=1.
2: reverse running (REV)
Short-circuit terminal with COM, VFD runs
reverse. Valid only when F0.06=1.
3: three-wire running control
Refer to function description of running
mode 2, 3 (three-wire control mode 1, 2) of
F7.11.
4: forward jog control
Short-circuit terminal with COM, VFD runs
as jog forward. Valid only when F0.06=1.
5: reverse jog control
Short-circuit terminal with COM, VFD runs
as jog reverse. Valid only when F0.06=1.
6: coast to stop
This function is the same with F1.08. Only
that it is realized by terminal and convenient
for remote control.
7: external reset signal input(RST)
If the VFD malfunctions, it can be reset
through this terminal. This function is the
same with key , and is valid in
any command channel.
8: external fault normally-open input
9: external fault normally-closed input
The fault signal of external device can be
input through this terminal so as to facilitate
fault monitoring of external device. After
receiving fault signal of external device,
VFD will display "E-19" (external device
fault alarm). The fault signal can be input
with two methods of normally open and
normally closed.
STOP/RESET
F7.00
Input terminal X1 function (when
F8.21 is non-zero, default as function
NO.58)
0～99 1
F7.01
Input terminal X2 function (when
F8.21 is non-zero, default as function
NO.59)
0～99 2
F7.02
Input terminal X3 function (when
F8.21 is non-zero, default as function
NO.60)
0～99 4
F7.03
Input terminal X4 function (when
F8.21 is non-zero, default as function
NO.61)
0～99 7
F7.04
Input terminal X5 function (when
F8.21 is non-zero, default as function
NO.62)
0～99 8
F7.05
Input terminal X6 function (when
F8.21 is non-zero, default as function
NO.63)
0～99 0
F7.06
Input terminal X7 function (high
speed impulse input)
0～99 45
F7.07
reserved
— 0
F7 digital input and output
