Sako SKI600 - Page 40

034
4.1 Function Code
F1 Group - Auxiliary Operating Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F1.00 Start mode
0: start at start frequency
1: DC braking + start at start
frequency
2: start with speed tracking
1 0 ×
F1.01 Start frequency 0.00 ～ 50.00Hz 0.01Hz 1.00 ○
F1.02
Start frequency hold
time
0.0 ～ 100.0s 0.1s 0.0 ○
F1.03
DC brake current at
startup
0.0 ～ 150.0％ *rated current
of motor
0.1% 0.0% ○
F1.04
DC brake time at
startup
0.0 ～ 100.0s 0.1s 0.0 ○
F1.05
Accelerating and
decelerating mode
0: linear Acc/Dec mode
1: S curve Acc/Dec mode
1 0 ×
F1.06
Time ratio of initial
segment in S curve
10.0 ～ 50.0％ 0.1% 20.0% ○
F1.07
Time ratio of ending
segment in S curve
10.0 ～ 50.0％ 0.1% 20.0% ○
F1.08 Stop mode
0: Decelerate to stop
1: coast to stop
1 0 ×
F1.09
Frequency threshold
of DC brake
0.00 ～【F0.16】upper limit
frequency
0.01Hz 0.00 ○
F1.10 DC brake delay time 0.0 ～ 100.0s 0.1s 0.0 ○
F1.11 DC brake current
0.0 ～ 150.0％ *rated current
of motor
0.1% 0.0% ○
F1.12 DC brake time at stop 0.0 ～ 100.0s 0.1s 0.0 ○
F1.13 Acc time 2
0.1 ～ 3600.0s
0.4 ～ 4.0KW 7.5s
5.5 ～ 30.0KW 15.0s
37.0 ～ 132.0KW 40.0s
160.0 ～ 630.0KW 60.0s
0.1
Depending
on model
○
F1.14 Dec time 2 0.1
Depending
on model
○
F1.15 Acc time 3 0.1
Depending
on model
○
F1.16 Dec time 3 0.1
Depending
on model
○
F1.17 Acc time 4 0.1
Depending
on model
○
F1.18 Dec time 4 0.1
Depending
on model
○
