041
F5 Group - VF Control Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F5.00 V/F curve set
0: linear curve
1: decreasing torque curve 1( 1.3
power)
2: decreasing torque curve 2(1.5
power)
3: decreasing torque curve 3(1.7
power)
4: square curve
5: user set V/F curve
(determined by F5.01 ～ F5.06)
1 0 ×
F5.01 V/F frequency F1 0.00 ～ F2 (frequency value) 0.01Hz 12.50 ×
F5.02 V/F voltage V1 0.0 ～ V2 (voltage value) 0.1% 25.0% ×
F5.03 V/F frequency F2 F1 ～ F3 (frequency value) 0.01Hz 25.00 ×
F5.04 V/F voltage V2 V1 -V3 (voltage value) 0.1% 50.0% ×
F5.05 V/F frequency F3
Freq. Value F2 ～ 【F2.02】rated
freq. of motor
0.01Hz 37.50 ×
F5.06 V/F voltage V3
Voltage value V2 ～ 100.0%*
【F2.04】rated voltage of motor
0.1% 75.0% ×
F5.07
Torque boost
setting
0.0 ～ 30.0%*rated voltage of
motor 【F2.04】
0.1%
Depending
on model
×
F5.08
Torque boost
cuto󽗈 point
0.00 ～ rated freq. of motor 0.01Hz 50.00 ×
F5.09
V/F control
slip frequency
compensation
0.0 ～ 200.0% *rated slip
note: default as 100.0% in
advanced VF control mode
0.1% 0.0% ○
F5.10
V/F control slip
compensation
󽗉ltering
coe󽗋cients
1～10 1 3 ○
F5.11
V/F control
torque
compensation
󽗉ltering
coe󽗋cients
0～10 1 0 ○
4.1 Function Code
