042
F5 Group - VF Control Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F5.12
Separated
type
V/F control
O: VF half separated mode, voltage
open-loop output
1: VF half separated mode, voltage
closed-loop output
2: VF complete separated mode,
voltage open-loop output
3: VF complete separated mode,
voltage closed-loop output Note
1: when choose VF separated
control, please close the dead-time
compensation function
Note 2: half separated concept
is based on that during start-up
the frequency and voltage of VFD
remains the VVVF relation, but get
separated after the reaching of set
frequency
1 0 ×
F5.13
Voltage setting
channel
0: digital setting
1: AI1
2: AI2
1 0 ○
F5.14
voltage
feedback
method of
voltage close-
loop output
0: AI1
1: AI2
note: only valid for closed loop
output mode
1 0 ×
F5.15
Output voltage
of digital
setting
0.0 ～ 200.0％ *rated voltage of motor
note: in open loop output mode,
the maximum output voltage is
100.0% of rated voltage of motor
0.1% 100.0% ○
F5.16
Deviation limit
of voltage
closed loop
regulation
0.0 ～ 5.0％ *rated voltage of motor 0.1％ 2.0% ×
4.1 Function Code
