044
4.1 Function Code
F6 Group - Analog Quantity and Pulse Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F6.00
AI1 input
corresponding
physical quantity
0: speed command (output
freq., -100.0% ～ 100.0%）
1: torque command (output
torque, -200.0% ～ 200.0%)
2: voltage command (output
voltage, 0.0% ～ 200.0% *rated
voltage of motor)
1 0 ×
F6.01 AI1 input lower-limit
0.00V/0.00mA ～ 10.00V/20.00mA 0.01V 0.00 ○
F6.02
AI1 lower limit
corresponding
physical quantity set
-200.0% ～ 200.0%
note: range is relevant to P6.00
0.1% 0.0% ○
F6.03 AI1 input upper limit
0.00V/0.00mA ～ 10.00V/20.00mA 0.01V 10.00 ○
F6.04
AI1 upper limit
corresponding
physical quantity
setting
-200.0% ～ 200.0%
note: range is relevant to P6.00
0.1% 100.0% ○
F6.05
AI1 input smoothing
time
0.00s ～ 10.00s 0.01s 0.05 ○
F6.06
AI2 input
corresponding
physical quantity
0: speed command (output
freq., -100.0% ～ 100.0%）
1: torque command (output
torque, -200.0% ～ 200.0%）
2: voltage command (output
voltage, 0.0% ～ 200.0%*
rated voltage of motor)
1 0 ×
F6.07 AI2 input lower limit 0.00V ～ 10.00V 0.01V 0.00 ○
F6.08
AI2 lower limit
corresponding
physical quantity
setting
-200.0% ～ 200.0%
note: range is relevant to P6.00
0.1% 0.0% ○
