4.1 Function Code
F6 Group - Analog Quantity and Pulse Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F6.21
AO1 multi-function
analog output
terminal
0: output frequency ( before
slip compensation)
1: output frequency (after slip
compensation)
2: set frequency
3: motor speed (estimated
value)
4: output current
5: output voltage
6: but voltage
7: PID speci󽗉ed value
8: PID feedback value
9: AI1
10: AI2
11: input pulse freq.
12: torque current
13: 󽗊ux current
1 0 ○
F6.22
A02 multi-function
analog output
terminal
1 4 ○
F6.23
DO multi-function
impulse output
terminal
1 11 ○
F6.24
Physical quantity
correspond to AO1
output lower limit
-200.0% ～ 200.0% 0.1% 0.0% ○
F6.25 AO1 output lower limit 0.00 ～ 10.00V 0.01V 0.00 ○
F6.26
Physical quantity
correspond to AO1
ouput upper limit
-200.0% ～ 200.0% 0.1% 100.0% ○
F6.27 AO1 output upper limit 0.00 ～ 10.00V 0.01V 10.00 ○
F6.28
Physical quantity
correspond to AO2
output lower limit
-200.0% ～ 200.0% 0.1% 0.0% ○
F6.29 AO2 output lower limit 0.00 ～ 10.00V 0.01V 0.00 ○
F6.30
Physical quantity
correspond to AO2
output upper limit
-200.0% ～ 200.0% 0.1% 100.0% ○
F6.31 AO2 output upper limit 0.00 ～ 10.00V 0.01V 10.00 ○
