4.1 Function Code
F6 Group - Analog Quantity and Pulse Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F6.32
Physical quantity
correspond to DO
output lower limit
-200.0% ～ 200.0% 0.1% 0.0% ○
F6.33 DO output lower limit 0.00 ～ 50.00KHz 0.01KHz 0.00 ○
F6.34
Physical quantity
correspond to DO
output upper limit
-200.0% ～ 200.0% 0.1% 100.0% ○
F6.35 DO output upper limit 0.00 ～ 50.00KHz 0.01KHz 50.00 ○
F6.36
AI multipoint curve
selection
the unit of LED: AI1
multipoint curve selection
0: forbidden
1: e󽗈ective
the tens of LED: AI2
multipoint curve selection
0: forbidden
1: e󽗈ective
the hundreds of LED:
anolog input signal
selection
0: AI1 and AI2 input signal
0 ～ 10V
1: AI1 input signal
4 ～ 20mA, AI2 input signal
0 ～ 10V
2: AI2 input signal
4 ～ 20mA, AI1 input signal
0 ～ 10V
3: AI1 and AI2 input signal
4 ～ 20mA
the thousands of LED:
reserved
1 00 ×
F6.37 AI1 curve min input 0.00 ～【F6.39】 0.01V 0.00 ○
F6.38
AI1 curve min input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with
F6.00
0.1% 0.0% ○
