Sako SKI600 - Page 54

048
4.1 Function Code
F6 Group - Analog Quantity and Pulse Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F6.39
AI1 curve in󽗊exion
point 1 input
【F6.37】～【F6.41】 0.01V 3.00 ○
F6.40
AI1 curve in󽗊exion
point 1 input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1% 30.0% ○
F6.41
AI1 curve in󽗊exion
point 2 input
【F6.39】～【F6.43】 0.01V 6.00 ○
F6.42
AI1 curve in󽗊exion
point 2 input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1% 60.0% ○
F6.43 AI1 curve max input 【F6.41】～ 10.00 0.01V 10.00 ○
F6.44
AI1 curve max input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1%
100.0% ○
F6.45 AI2 curve min input 0.00 ～【F6.47】 0.01V 0.00 ○
F6.46
AI2 curve min input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1% 0.0% ○
F6.47
AI2 curve in󽗊exion
point 1 input
【F6.45】～【F6.49】 0.01V 3.00 ○
F6.48
AI2 curve in󽗊exion
point 1 input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1% 30.0% ○
F6.49
AI2 curve in󽗊exion
point 2 input
【F6.47】～【F6.51】 0.01V 6.00 ○
F6.50
AI2 curve in󽗊exion
point 2 input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1% 60.0% ○
F6.51 AI2 curve max input 【F6.49】～ 10.00 0.01V 10.00 ○
F6.52
AI2 curve max input
Corresponding setting
-200.0% ～ 200.0%
Note: range associated with F6.00
0.1%
100.0% ○
F6.53
AI1 input voltage
protection upper limit
【6.54】～ 10.00V 0.01V 6.80 ○
F6.54
AI1 input voltage
protection lower limit
0.00V ～【6.53】 0.01V 3.10 ○
