049
4.1 Function Code
F7 Group - Digital Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F7.00
Input X1
function
(when F8.21 is
non-zero,
default as
function NO.58)
0: control terminal idle
1: forward run (FWD)
2: reverse run (REV)
3: three-wire running control
4: forward jog control
5: reverse jog control
6: free shutdown control
7: external reset signal input(RST)
8: external fault normally-open input
9: external fault normally-close input
10: emergency stop function (brake
with)
11: reserved
12: freq.increase
13: freq.decrease
14: UP/DOWN terminal freq. zero
clearing
15: multi-speed 1
16: multi-speed 2
17: multi-speed 3
18: multi-speed 4
19: ACC/DEC time TT1
20: ACC/DEC time TT2
21: run command channel 1
22: run command channel 2
23: VFD ACC/DEC prohibit
24: VFD operation prohibiting
25: run command switch to keypad
26: run command switch to terminal
27: run command switch to
communication
28: auxiliary freq. zero clearing
29: freq. source A and K*B switch
30: freq. source A and A+K*B switch
31: freq. source A and A-K*B switch
1 1 ×
F7.01
Input X2
function (when
F8.21 is non-
zero, default as
function NO.59)
1 2 ×
F7.02
Input X3
function (when
F8.21 is non-
zero, default as
function NO.60)
1 4 ×
F7.03
Input X4
function (when
F8.21 is non-
zero, default as
function NO.61)
1 7 ×
