Sakura Tissue-Tek Xpress x120 User Manual

CARE OF THE INSTRUMENT
7.12 Revised 10/02/2012
1. Open the Fume Control System Access Door (Figure
7-W).
Figure 7-W
2. Release the latch securing the fume filter access door
(Figure 7-X) and open the access door.
Figure 7-X
3. Unlock the latch securing the fume filter cover (Figure
7-Y) and lift the cover up.
Figure 7-Y
4. Slide the fume filter out of the instrument (Figure 7-Z).
Figure 7-Z
5. Install a new fume filter in the instrument. Lower the
fume filter cover and secure the cover latch.
6. Close the fume filter access door and secure the door
latch (Figure 7-AA).
Figure 7-AA
7. Close the Fume Control System Access Door.
