2.1 Package content
1) iT500TR Thermostat
2) iT500RX Receiver
3) iTG500 Gateway
4) Optional Stand
5) ADSL Cable
6) iTA500 Power adaptor
7) Fixing screws & plugs
8) Wall mount bracket
9) Wall-box cover
2.2 Proper thermostat location
Please note:
The ideal position to thermostat mounting is about 1,5m under oor level far from heating or cooling sources. Thermostat can’t be
exposed to sunlight or any extreme conditions like for example draft.
Because of re and explosion risk there is not allowed to use thermostat in atmosphere of explosive gases and ammable liquids (eg coal dust). In case
if any of listed dangers occur you have to use additional protection measures – anti-dust and explosive gases (tight cover) or prevent their formation.
Furthermore, thermostat can’t be used in condensation of water vapor conditions and be exposed to water action.
1 2 3
654
7
8 9
