Product Specifications
SAM4S ER-350 SERIES 2-3
2-2 Appearance
2-2-1 Appearance Dimensions (mm)
Figure2-1 Dimensions
2-2-2 Feature Locations
Figure2-2 Feature Locations
① Printer Cover
② Impact Dot Printer
③ Keyboard
④ Drawer
⑤ Drawer Lock Key
⑥ Mode Switch
⑦ RS-232 Serial I/F Connector
⑧ Operator Display
⑨ Rear Display
