SAM4S ER-350 SERIES 9-1
9 PCB Parts List
9-1 Main PCB Parts List
No Code-No Description/Specification Q'ty Design-Location Serviceable Remar
k
JK94-00276B PRA ETC-MPCB:ER-350F,RUSB,RUSSIA,SENSOR 1
JK92-00128L PBA MAIN-MAIN BOARD:ER-350F,RUSB,RUSSIA, 1
0201-000008 ADHESIVE-HM:#3748,WHT,6500CPS,V2 1 TRANS
0201-000008 ADHESIVE-HM:#3748,WHT,6500CPS,V2 1
0202-000118 SOLDER-WIRE:KR-19 RMA,-,D0.8,-,- 1
0202-000216 SOLDER-BAR:S63S-B20,S63S,350X34,SN63/PB3 1
0202-001025 SOLDER-WIRE FLUX:KS-611,-,-,-,spray 1
0204-000004 ETHANOL:ISO-PROPYLEME,C2H50H,99.8%,- 1
0402-000168 DIODE-RECTIFIER:1N5822,40V,3A,DO-201AD,T 1 D2
0402-000287 DIODE-BRIDGE:GBL01,100V,3A,SIP-4,ST 1 B.D1
0502-000240 TR-POWER:KSA614-Y,PNP,25W,TO-220,TP,120 1 Q11(FISCAL)
0502-000288 TR-POWER:KSD288,NPN,25W,TO-220,-,120-24 1 Q8
0506-001019 TR-ARRAY:STA471A,NPN,4,4W,SIP-10,ST,200 1 TRA1
0506-001019 TR-ARRAY:STA471A,NPN,4,4W,SIP-10,ST,200 2 TRA2,TRA3
0801-000522 IC-CMOS LOGIC:74HCT541,BUFFER/DRIVER,DIP 2 IC5,IC14
0801-000528 IC-CMOS LOGIC:74HCT574,D FLIP-FLOP,DIP,2 2 IC6, IC7
0801-000530 IC-CMOS LOGIC:74HCT573,D LATCH,DIP,20P,3 1 IC12
0801-000918 IC-CMOS LOGIC:74HCT139,1-TO-4 DECODER,DI 1 IC10
0803-001206 IC-TTL:74LS05,INVERTED GATE,DIP,14P,3 2 IC8,IC9
0803-001211 IC-TTL:74LS14,SCHMITT INVERTER,DIP,14P,3 1 IC4
0903-001083 IC-MICROCONTROLLER:78C32B,8BIT,DIP,40P,- 1 IC11(WINBOND,78B32
0904-000251 IC-PERIPHERAL:82C55,8BIT,DIP,40P,-,-,-,C 1 IC17(FISCAL)
0909-000111 IC-REAL TIME CLOCK:5C15,4BIT,DIP,18P,300 1 IC13
1102-000173 IC-EPROM:27C512,64Kx8BIT,DIP,28P,600MIL 1 IC15
1106-001095 IC-SRAM:62256,32Kx8BIT,DIP,28P,600MIL, 1 IC16
1202-000103 IC-VOLTAGE COMP.:393,DIP,8P,300MIL,DUAL, 1 IC2
1203-000391 IC-DC/DC CONVERTER:34063,DIP,8P,250MIL,P 1 IC1
1203-000442 IC-POSI.FIXED REG.:7812,TO-220,3P,-,PLAS 1 IC18(FISCAL)
1206-000139 IC-TIMER:NE555CN,DIP,8P,250MIL,PLASTIC, 1 IC3
2003-000502 R-METAL OXIDE(S):150ohm,5%,2W,AA,TP,4x12 1 R42
2011-000290 R-NETWORK:1KOHM,5%,1/8W,A,SIP,10P,BK 1 RA5
2011-000539 R-NETWORK:4.7KOHM,5%,1/8W,A,SIP,9P,ST 4 RA1,2,3,4
2201-000539 C-CERAMIC,DISC:4.7nF,20%,250V,Y5V,BK,16x 1 C1
2401-001312 C-AL:4700uF,20%,50V,GP,BK,22x40,10 1 CE1
2401-001363 C-AL:470uF,20%,16V,GP,TP,10x12.5,5 1 CE7
2401-001429 C-AL:470uF,20%,50V,GP,TP,13x20,5 1 CE6
2503-001030 C-NETWORK:100PFX8,20%,50V,X7R 6 CA1,3,4,5,6,7
2801-000140 CRYSTAL-UNIT:12MHz,50ppm,28-AAM,S,30ohm, 1 X2
2801-003376 CRYSTAL-UNIT:0.032768MHz,20ppm,28-AAY,12 1 X1
3002-001027 BUZZER-PIEZO:85dB,1.5V,24mA,2.048KHz,BK 1 BUZZER
3601-000246 FUSE-CARTRIDGE:250V,2A,TIME-LAG,GLASS,5. 1 FUSE
3704-000235 SOCKET-IC:28P,DIP,SN,2.54mm 1 IC15
3708-000306 CONNECTOR-FPC/FFC/PIC:6P,2.54mm,STRAIGHT 1 CN13
3708-000327 CONNECTOR-FPC/FFC/PIC:8P,2.54mm,STRAIGHT 1 CN14
3710-000111 CONNECTOR-SHUNT:2P,1R,2.54mm,-,AUF 1 CN11(ALL CLEAR)
3711-000033 CONNECTOR-HEADER:BOX,2P,1R,2.5mm,STRAIGH 1 CN2(DISPLAY/VF),RE
3711-000034 CONNECTOR-HEADER:BOX,2P,1R,2.5mm,STRAIGH 1 CN9(MOTOR),BLK
3711-000037 CONNECTOR-HEADER:BOX,3P,1R,2.5mm,STRAIGH 2 CN4,17(P/SENSOR),RED
3711-000041 CONNECTOR-HEADER:BOX,8P,1R,2.5mm,STRAIGH 1 CN6(DISPLAY),RED
3711-000183 CONNECTOR-HEADER:1WALL,2P,1R,3.96mm,STRA 1 CN16(DRAWER)
3711-000658 CONNECTOR-HEADER:BOX,12P,1R,2.5mm,STRAIG 1 PRT 12P
3711-000829 CONNECTOR-HEADER:BOX,2P,1R,6.2mm,STRAIGH 1 CN1(POWER CORD)
3711-001011 CONNECTOR-HEADER:BOX,5P,1R,2.5mm,STRAIGH 1 CN7(RS-232C),IVORY
3711-001133 CONNECTOR-HEADER:BOX,8P,1R,2.5mm,STRAIGH 1 CN12(MODE KEY),IVO
