9. PCB Parts List
9-2 SAM4S ER-350 SERIES
9-1 Main PCB Parts List
No Code-No Description/Specification Q'ty Design-Location Serviceable Remar
k
3711-001475 CONNECTOR-HEADER:NOWALL,3P,1R,2.54mm,STR 1 CN11(ALL CLEAR)
3711-001962 CONNECTOR-HEADER:NOWALL,30P,2R,2.54mm,ST 1 CN15(FISCAL)
3711-003359 CONNECTOR-HEADER:BOX,10P,1R,2.5mm,STRAIG 1 PRT 10P
3711-003969 CONNECTOR-HEADER:BOX,2P,1R,2.5mm,STRAIGH 1 CN5(COMPULSORY)IVO
4302-000126 BATTERY-NICD(2ND):3.6V(1.2Vx3),60mAH,CYL 1 BAT1
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 1 JP149(FISCAL)
JC68-10564A LABEL(P)-PROTECTOR:SLB-3108H,ART,-,100(S 1 FISCAL BOARD
JC68-10564A LABEL(P)-PROTECTOR:SLB-3108H,ART,-,100(S 1 IC15
JK26-30100A TRANS POWER:ER-350,230V/50Hz,AWG#22 1 POWER TRANS
JK27-60100D COIL FILTER:ER-350,140 UH,-,- 1 L1
JK39-40307D CBF HARNESS:ER-4615FP,-,UL1007,310MM,RED 1 PRT 10P/12P
JK39-40550A CBF HARNESS-JUMPER:ER-350F,WIRE,UL1007,1 1 A_TO_A
JK92-00133A PBA MAIN-PCB AUTO:ER-350,SAMSUNG,BASIC,- 1 MAIN AUTO
JK96-00940A ELA HOU-HEAT SINK:ER-4615,BASIC,WORLD,-, 1 Q1
0205-000003 OIL-SILICON:G746,- 0
0401-000005 DIODE-SWITCHING:1N4148,100V,200mA,DO-35, 12
D15,D24,D18,D21
D17,D16,D22,D19 D1,D10
D11,D20
0402-000129 DIODE-RECTIFIER:1N4003,200V,1A,DO-41,TP 7 D12,D5,D6,D3,D7,D8 D4
0402-000208 DIODE-RECTIFIER:EK-04,40V,1.5A,DO-41 4 D13,D9,D14,D25
0403-000141 DIODE-ZENER:1N4735A,6.2V,5%,1W,DO-41,TP 1 ZD4,5
0403-000343 DIODE-ZENER:UZ3.9B,3.9V,3.7-4.1V,500mW,D 1 R21
0403-000343 DIODE-ZENER:UZ3.9B,3.9V,3.7-4.1V,500mW,D 1 ZD3
0403-000537 DIODE-ZENER:1N4749A,24V,5%,1W,DO-41,TP 1 ZD1
0501-000399 TR-SMALL SIGNAL:KSC945-G,NPN,250mW,TO-92 8
Q10,Q4,Q3,Q6,Q5,Q7
Q2,Q9
0502-000395 TR-POWER:-,NPN,30W,TO-220,-,120-240 1
2001-000027 R-CARBON:100OHM,5%,1/4W,AA,TP,2.4X6.4MM 3 R33,34,35
2001-000032 R-CARBON:180OHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R58,44
2001-000034 R-CARBON:220OHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R53
2001-000036 R-CARBON:330OHM,5%,1/4W,AA,TP,2.4X6.4MM 3 R37,52,54
2001-000042 R-CARBON:1KOHM,5%,1/4W,AA,TP,2.4X6.4MM 12
R38,R24,R40,R48
R49,R45,R28,R13
R41,R22,R11,R39
2001-000047 R-CARBON:2.2KOHM,5%,1/4W,AA,TP,2.4X6.4MM 4 R26,7,25,60
2001-000055 R-CARBON:4.7KOHM,5%,1/4W,AA,TP,2.4X6.4MM 8
R10,R8,R2,R14,R50
R16,R15,R6
2001-000060 R-CARBON:6.8KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R12,51
2001-000065 R-CARBON:10KOHM,5%,1/4W,AA,TP,2.4X6.4MM 7
R56,R29,R20,R23,R3
R43,R27
2001-000076 R-CARBON:47KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R19
2001-000113 R-CARBON:18KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R18
2001-000323 R-CARBON:120OHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R55
2001-000395 R-CARBON:180KOHM,5%,1/4W,AA,TP,2.4X6.4MM 3 R30,31,32
2001-000561 R-CARBON:27KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R17
2001-000588 R-CARBON:3.3KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R36
2001-000841 R-CARBON:51OHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R9
2004-000284 R-METAL:12Kohm,1%,1/4W,AA,TP,2.4x6.4mm 1 R5
2004-000825 R-METAL:36Kohm,1%,1/4W,AB,TP,2.4x6.4mm 1 R4
2005-000419 R-WIRE WOUND,NON:0.33ohm,1%,1W,AA,TP,4.3 1 R1
2201-000119 C-CERAMIC,DISC:100nF,+80-20%,50V,Y5V,TP, 25
C38,C32,C16,C17,C3
C23,C33,C15,C22,C8
C41,C37,C45,C28
C14,C46,C27,C21
C26,C4,C6,C29,C30
C40,C18
To Next Page
