9. PCB Parts List
SAM4S ER-350 SERIES 9-3
9-1 Main PCB Parts List
No Code-No Description/Specification Q'ty Design-Location Serviceable Remar
k
2201-000162 C-CERAMIC,DISC:10nF,+80-20%,50V,Y5V,TP,7 3 C11,12,13
2201-000232 C-CERAMIC,DISC:0.15nF,10%,50V,Y5P,TP,4x3 1 C7
2201-000464 C-CERAMIC,DISC:0.03nF,5%,50V,SL,TP,5x3,5 4 C34,35,24,25
2201-000764 C-CERAMIC,DISC:0.082nF,5%,50V,NP0,TP,8x3 2 C42,36
2301-000010 C-FILM,PEF:100nF,5%,100V,TP,11.5x12.5mm, 3 C5,C9,C10
2401-000032 C-AL:100uF,20%,50V,GP,TP,8x12,5mm 1 CE2
2401-000042 C-AL:100uF,20%,16V,GP,TP,6.3x7,5 4 CE4,5,8,9
2401-000480 C-AL:10uF,20%,50V,GP,TP,5x11,5 1 CE3
2401-000603 C-AL:1uF,20%,50V,GP,TP,5x11,5 1 CE11
2401-002075 C-AL:4.7uF,20%,50V,GP,TP,5x11,5 1 CE10
3301-000299 CORE-FERRITE BEAD:AA,3.6x5.0mm,550,3100G 2 FB2,3
3301-000344 CORE-FERRITE BEAD:AA,-,3.5x0.6x6.5mm,-,- 4 FB1,4,5,6
3602-000001 FUSE-CLIP:-,-,30mohm 2 FH1
6002-000175 SCREW-TAPPING:PWH,+,2,M3,L8,ZPC(YEL) 1
6203-000107 HEAT SINK:NONE,T2,W17,L22,H45,DEGRE,AL60 1
jb02-10501a TAPE ETC-SEQ M/C:TESLA,-,T0.12,W6,L3000M 0
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 16 JP1-JP16
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 131 JP18-JP148
JK41-10001A PCB-MAIN:ER-380,FR-1,1L,T1.6,300X130XT1 1 MAIN PCB
9-2 Font Display Parts List
No Code-No Description/Specification Q'ty Design-Location Serviceable Remar
k
JK92-01243A PBA DISPLAY:ER-350F,FUTABA,RUSB 1
2401-001050 C-AL:3300uF,20%,10V,SHL,VB,12.5x20,5mm 1 C1
3711-001133 CONNECTOR-HEADER:BOX,8P,1R,2.5mm,STRAIGH 1 CN1
3711-002002 CONNECTOR-HEADER:-,22P,2R,2mm,STRAIGHT,S 1 CN2
3711-003969 CONNECTOR-HEADER:BOX,2P,1R,2.5mm,STRAIGH 1 CN3
JK07-00005A DISPLAY VFD-DC10G:FUTABA,10-LT-50GK 1 V1
JK39-00034A CONNECT WIRE-350 DISPLAY:ER-350,FLAT,UL1 1 8P
JK39-40006A CBF HARNESS:ER-350,-,UL1007,350MM,WHT/RE 1 2P
JK73-10207A RPR-PAD:ER-220N,SPONGE,-,BLK,- 2 T5.0
1003-001381 IC-VFD:HV5812P,DIP,28P,540MIL,-,-,ST,PLA 1 U1
JK69-90902A PACKING-VINYL:PET,#2126,30X100000XT0.05, 0 DIGITRON
JK94-01120B PHANTOM AU JK92-01243A 1
0402-000129 DIODE-RECTIFIER:1N4003,200V,1A,DO-41,TP 1 D1
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 5 J1,J2,J3,J4,J5
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 5 J6,J7,J8,J9,J10
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 5 J11,J12,J13,J14,
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 4 J16,J17,J18,J20
JK41-10005B PCB-DISPLAY(10G):ER-350/F,FR-1,1L,T1.6,F 1
9-3 Rear Display Parts List
No Code-No Description/Specification Q'ty Design-Location Serviceable Remar
k
JK92-01231A PBA TURRET:ER-350F/5100/5200,10G 1
JK39-40002A CBF HARNESS:ER-220N,-,UL1061,400MM,BLK/R 1 TURRET TO DISP.
JK07-00005A DISPLAY VFD-DC10G:FUTABA,10-LT-50GK 1 10 DIGIT
3711-002812 CONNECTOR-HEADER:BOX,11P,1R,2mm,STRAIGHT 2 CN1,CN2
JK73-10207A RPR-PAD:ER-220N,SPONGE,-,BLK,- 2 PAD
JK69-90902A PACKING-VINYL:PET,#2126,30X100000XT0.05, 0 DIGITRON
JK94-00053A PHANTOM AUTO ER-290 TURRET 10DIT 1
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 5 J1,J2,J3,J4,J5
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 1 J6
JK41-10548B PCB-TURRET:ER-5100/5200,FR-1,1L,T1.6 1 10 DIGIT
