9. PCB Parts List
9-4 SAM4S ER-350 SERIES
9-4 Fiscal Board Parts List(Memory Size=1MBits)
No
Code No. Description / Specification Q’TY Remarks Serviceable
JK92-00132B PBA SUB-FISCAL B/D;1MBITs 1 1MBITs ASSY
Y
1102-000109 IC-EPROM:27C010,128Kx8BIT,DIP,32P,600MI 1 U1
Y
0403-000141 DIODE-ZENER:1N4735A,6.2V,5%,1W,DO-41,TP 1 ZD1
Y
JK39-40305B CBF HARNESS:,-,UL 1007,120,WHT/BLU/RED,2 1 CN1
Y
JK94-00055A PHANTOM AU JK92-00132B 1 N
2007-000029 R-CHIP:0OHM,5%,1/10W,DA,TP,2012 1 R3 Y
2007-000030 R-CHIP:560OHM,5%,1/10W,DA,TP,2012 1 R2 Y
2007-000221 R-CHIP:1.2KOHM,5%,1/10W,DA,TP,2012 1 R4 Y
2007-000872 R-CHIP:4.7KOHM,5%,1/10W,DA,TP,2012 10
R1,R5,R6,R7,R8,R9,R10,R11
R12,R13
Y
2203-000192 C-CERAMIC,CHIP:100nF,+80-20%,50V,Y5V,TP, 1 C2 Y
0404-001051 DIODE-SCHOTTKY:SK14,40V,1000MA,DO-214AA, 2 D1,D2 Y
0501-000457 TR-SMALL SIGNAL:MMBT2222A,NPN,350MW,SOT- 1 Q1 Y
JK41-10531B PCB-FISCAL:ER-5240F,FR-4,2L,T1.6mm,348X5 1 Y
9-5 Interface Board Parts List
No Code-No Description / Specifications Q'ty Design-Location Serviceable Remark
JK92-00105A PBA MAIN-I/F BOARD:ER-350P,SAMSUNG,CE,-, 1
3701-000240 CONNECTOR-DSUB:9P,2R,FEMALE,STRAIGHT,AUF 1 CN2(18PCS)
1006-000137 IC-DRIVER/RECEIVER:232,DIP,16P,300MIL,DU 1 IC 1
JK39-40011A CBF HARNESS:ER-350,-,UL1015,250MM,GRN/YE 1 GND WIRE
JK60-10500A SCREW-SPECIAL:-,-,M2.6,L6,-,-,-,-,ZPC3,S 2 HEX,M3
6003-000266 SCREW-TAPTITE:PWH,+,S,M3,L6,ZPC(YEL),SWR 1 I/F BRKT + GND WIR
JK39-40305U CBF HARNESS:,-,UL 1007,200,RED/WHT/WHT/W 1 CN1(18PCS)
JK70-10003A IPR-BRKT PORT:ER-380,SBHG-1,T1,- 1
SEGI-100047 EGI 1.0*47*33 1
JK92-00134A PBA MAIN-I/F AUTO:ER-350,SAMSUNG,EUROPE, 1
JK41-10004A PCB-INTERFACE:ER-380,FR-1,1L,T1.6,40X43X 1 PCB(6PCS)
3301-000292 CORE-FERRITE BEAD:AA,100ohm,3.5x0.6x6.5m 2 FB1,2(6PCS)
0501-000399 TR-SMALL SIGNAL:KSC945-G,NPN,250mW,TO-92 2 Q1,Q2
2001-000047 R-CARBON:2.2KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R2
2001-000055 R-CARBON:4.7KOHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R1
2001-000065 R-CARBON:10KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R3,R4
2401-002075 C-AL:4.7uF,20%,50V,GP,TP,5x11,5 2 C4,5(6PCS)
JC39-40511A CBF HARNESS:ML-80,JUMPER,AWG22,52mm,SILV 3 J1,2,3(6PCS)
2401-000480 C-AL:10uF,20%,50V,GP,TP,5x11,5 3 C1,C2,C3
