HCUBE-102D Service Manual
2.2 Assemble the printer
It’s only necessary to assemble in the opposite order of disassembling.
Notes:
1) When assembling the paper container unit, it should correspond to the corresponding
slot of the lower cover. It is recommended to take photos as a reference before
disassembling the printer.
2) When assembling the paper container, the top cover open angle should be less than the
maximum.
3) After assembling, it means that the assembly is correct when the top cover can be
opened and closed normally.
