Sam4s HCUBE-102D User Manual

HCUBE-102D Service Manual
17
5.2 Printer Components List
NO.
Description
Quantity
Remarks
1
Front Panel
1
2
Indicator Panel Holder
1
3
Indicator Panel
1
4
Light Guide
1
5
2.0*3.0 PWBHZn
2
Lock guide
6
3.0*8.0 PBHZn
2
Lock indicator panel holder
7
3.0*8.0 PBHZn
2
Lock main board
8
2.0*3.0 PWBHZn
2
Lock communications veneer
9
Control Mainboard
1
10
Motor
1
11
Cutter Unit
1
12
2.5*5.0*8.0 PWBHZn
2
Lock cutter unit
13
Torsion Spring
1
14
Key Press Rod
1
15
Cover Opening Lever
2
16
Nut
2
17
Cutter Cover
1
18
TPH Unit
1
19
TPH Spring
2
20
Button Spring
1
21
Cover Opening Button
1
22
Buffer Foam
2
23
3.0*8.0 PBHZn
2
Lock platen unit
24
Platen Unit
1
25
Top Cover
1
26
Guide Paper Decoration
1
27
Paper Guide
2
28
Guide Gasket (left+right)
1+1
29
Main Holder
1
30
Torsion Spring (R+L)
1+1
31
Top Cover Shaft
2
32
TPH Shaft
1
33
Drive Gear 2
1
34
Drive Gear 1
1
35
3.0*8.0 PBHZn
3
Lock gear cover plate
36
Gear Cover Plate
1
37
3.0*5.0 PMHNi
2
Lock paper motor
