HCUBE-102D Service Manual
2 Main Components Disassembling and Assembling
Cautions during operation:
1) When printer is working, do not disassemble any component of it and do not loosen any
screws.
2) When disassembling components, carefully check whether the connectors are damaged
or not.
3) Handle the printing head or other electronic components in the process, pay attention
to prevent static electricity.
4) Do not let screws or other components into inner of printer during disassembling.
5) Avoid printer mechanism being damaged when assembling and disassembling.
Maintenance tool: Cross screw driver, normal screwdriver, cutting pliers.
Auxiliary materials: Lubricating grease, alcohol, rayon balls.
