42
Using the Numeric Data Entry keys, enter the Bank LSB value you want to send.
Cancel
Panic
Data Contr Assign
Bank MSB
Bank LSB
Program
Default
9
8
7
6
5
4
3
2
1
0
Enter
NOTE
As an alternative to using the Numeric Data Entry Keys, you could instead use the
Data Control knob to choose the Bank LSB value in this step.
Press the Enter Key (C7) to send the MIDI command.
Cancel
Panic
Data Contr Assign
Bank MSB
Bank LSB
Program
Default
9
8
7
6
5
4
3
2
1
0
Enter
2.To Assign the Data Control Knob to Send Bank LSB Changes:
Press the [Voice/Function] button to enter Function Mode.
Voice / -
Function
Press the Bank LSB Data Control Key (Ab1).
The LED display will momentarily show:
NOTE
That this is different than the Bank LSB Key (Ab5) that you used to input a
single Bank LSB value.
Ab1
