Mountingoncontrolvalves
Securingthealignedcamdisk
To prevent the cam disk from turning, drill a
holeintotheadapter(36)orcoupling(44)
toallowa2mmdowelpintobeinserted.
Select one of the four holes located around
the center hole of the cam disk to secure the
cam disk in position.
